From the Archives

All Torque Transmissions has been around since 1996 and in that time we have had some weird and wonderful stuff come through the doors. The below images are from our first website and give a snap shot of some of the things we have been involved with. How young are Rob and Craig in some of the photos?

Bonfiglioli Transmital Planetary Drive, complete with IEC Scorpion motor.

Bonfiglioli Shaft mount ‘TA 125’ series in for repair.

Bonfiglioli Shaft mount ‘TA 125’ series fully rebuilt.

All Torque special design – The beginnings of a parallel helical fabricated       gearbox – custom made for Blue Scope Steel.

All Torque special design – Blue Scope special gearbox mid production.

All Torque special design – Blue Scope special gearbox completed, and ready for service on site.

Stone Wallwork PIV TE4A and TE5A Variator – completed repairs.

Preparing Bonfiglioli double reduction worm gearboxes complete with WEG motors.

Link Belt PIV – Fully repaired & ready for service.

Special gearing, including these large 11 module spur gears, 64mm face width with Taper bushes.

Bonfiglioli Transmital Right angle Planetary gearbox.

Bonfiglioli Transmital Right angle Planetary drives complete with cooling fans.

‘FU’ variator after repair.

Combination variable speed drive, SEW geared unit, complete with Siti variator & WEG motor, fitted and tested.

Bonfiglioli Shaft mount ‘TA 125’ series in overhaul stage.

Bonfiglioli Shaft mount ‘TA 125’ repaired – ready for service again.

All Torque special design – The beginnings of a parallel helical fabricated gearbox – custom made for Blue Scope Steel.

All Torque special design – Blue Scope special gearbox internals.

Stone Wallwork PIV TE 5A Variators – internals.

PIV Linkbelt variator. Restored to original condition – with new chain, wheel       faces, bearings etc.

Finished, modified and repaired KHS (Germany) Spiral Bevel & worm box combination.

Bonfiglioli ‘W86’ complete with Adaption-Special to incorporate hydraulic motor fitted.

Bonfiglioli Transmital Planetary gearbox complete with WEG brake, motor and special       safety guard.

PIV type 2A repair, about to be converted and test run.

PIV variator, new unit supplied from PIV Germany – complete with locally fitted         Bonfiglioli Torque Limited worm gear motor as servo speed control.

PIV phase shifting drive, overhauled complete with toothed clutch replaced.

Toothed clutch fitted to repaired PIV phase shifting gearbox.

Tandler spiral bevel gearbox, replacement unit.

Telcomec pneumatic toothed clutch, 1 of 6 units.

ASB331 PIV repair.

ALLSPEEDS Kopp 316 variator overhauled.

‘AO’ type PIV variator – Fully refurbished.

Flender Cavex gearbox refurbishment.

Marzorati phase changing gearbox rebuilds X 6.

piv gear

PIV repair, type WKS7G2.

PIV type KSGO-U2 variator,replacement unit.

Trasmital Planetary Drive, vertical up-mount.

PIV replacement chain (left side old, right side new) – original chain from PIV Germany held in our stock.

Bonfiglioli ‘F’ series helical, complete with brake motor.

SEW geared motor complete with OMC Comintec torque limiter Ball detent Coupling       device.

Marzorati phase changing gearbox rebuild.

Link Belt PIV rebuilt 7 ready for service.

WEG mining motor coupled to Flender in-line helical gearbox – adapted to Flender helical via.

Bonfiglioli       motorised door drive complete with brake motor, ‘W’ series gearbox, & retrofitted limit switch box.

Baldor USA special Mail Handling motor, Warner USA clutch brake unit all fitted       to Winsmith worm box.

PIV Windsor drives – rebuilds for newspaper industry.

Bevel helical shaft mounted gearbox, complete with WEG motor.

Bonfiglioli worm box – mechanical 5:1 ratio variator and WEG motor.

An example of 3 phase motors and DC motor with controller.

Our in house assembly provides fitments of all brands of motors and gearboxes.

500-off Machined Double row sprockets each fitted in house with 2 x sealed for life       bearings.

An Italian speed increaser gearbox setup for P.T.O. input into pump application.

DC motor/Clutch-Brake/in-line helical gearbox adaption is a daily occurrence!

1200 Diameter x 24 Groove section ‘8V’ pulley ready for delivery for 1500 HP       woodchip drive.

PIV Germany Variable speed drives – repairs and spares. Rebuilt unit ready for       dispatch.

We can tell you about all of these brand examples and more.

On the truck, ready for delivery on site.

Matrix air tooth clutch, replaced with Telcomec (Italy) unit.

One of 2 only 1500 diameter x 20 groove SPC pulleys. Both Australian made for       Hammer mill application.

Bonfiglioli MVF110 repair with DC motor & Tacho generator.

W86 worm gearbox with HS (High Speed) input.

Bonfiglioli Power transmission gearboxes, Variable speed drives etc.

Bonfiglioli geared drives – ready for delivery.

Warner Electric clutch adapted by All Torque to clients cable wheel drive.

WE TURNED THIS…

INTO THIS – We specialise in refurbishment and rebuilding.

Young All Torque mascot ‘Craig’ checks the tyre pressure before final delivery       of this geared motor.

‘The oil level is fine’.

Our in house belt drive design – photograph of pulley (from previous picture)       installed with 2 motor pulleys 12 groove and 24 belt drive on 2 X 750 HP motors.

PIV Germany Compound variable speed unit in for repair.

LEAGUE OF NATIONS – combination of product from 5 countries – Perfect mix for this client.   Flame cut-two piece segment sprocket for drum drive   You want all one brand to suit your needs – WE CAN SUPPLY IT!   11-off 2.2 KW invertors in IP 41 enclosure – also IP 55 version shown at right   ‘One Off’ import clutches and tensioners from the USA supplied by a reputable       American P.T. house   ‘A small example of the company we keep’ – Drives include Bonfiglioli,Stroter,Warner       Electric,Siemens etc   In-line Gearbox with enclosed mechanical variator   The beginnings of a Transit Mixer-concrete truck driven sprocket   Shimpo – Japan. a direct import and P.T. partner   This extruder gearbox was repaired ‘in house’ with locally made hardened and       ground helical input gearing set   In-line helical gear heads, Retro-fitted with D.I.P. hazardous location motors for       grain conveyors   Siemens motor with Rotor shaft modified for Left Hand threaded nuts   All brands of gearboxes and P.T. equipment available from our USA contacts   2 x Bonfiglioli Italian shaft mounted helical bevel geard motors – ready for       installation   AC Eddy current drives.Old technology but perfect for some applications!   All Torque’s new workshop in Braeside (inside view).
